SECTION 5: OPTIONAL ACCESSORIES
5.1 Air Shield for Applications in Contaminated Environment
(Part No. DASA1-P)
For installation in areas with high levels of airborne contaminants the
Detector Air Shield should be mounted to the Flame Detector housing. The
Airline fitting accepts ¼” O.D. nylon tubing for an instrument grade air
supply of 5 to 15 psi @ 6 cubic ft. per minute.
5.2 PC Software Kit (2029-INTERFACE-KIT)
PC DOS Software Kit installation facilitates access to FirePic and
SnapShot and provides Detectors operation monitoring capability through
the Detector’s RS485 connections. The Kit includes an Interface Box, a PC
software diskette, an RS485 and RS232 cables, and a 120 VAC/12 VDC
charger. Optional 220 VAC/12 VDC charger is also available upon request.
5.3 4-20 mA Option (MA420-4)
The 4-20 mA module is by Factory Mutual (FM) recognized device to be
used with all approved SS4 type Detectors. Honeywell Analytics is required
by FM to install this device at the factory and certifies this option along with
the Detector. Refer to Section 2.2.5 for system wiring details.
NOTE: Converting Field units of the SS4 Stand-alone relay type to
the 4-20 mA version requires the unit be returned to the factory for
installation and certification.
5.4 Detector Mounts (SM2 or SM4)
The heavy duty steel Swivel Mount (SM2) or extra duty Stainless Steel
Swivel Mount (SM4) may be utilized for mounting the SS4 type Detectors.
Refer to Section 2.3 for details.
5.5 Test Lamp (FT-2045 or FT-2145)
This battery powered, portable, explosion-proof handheld test source for
remote activation of the SS4 type Detectors simulates the radiant energy
emitted by an actual fire in order to test the Detectors operation without the
need for an open flame. The unit is rechargeable with a 120VAC / 12VDC
charger. Optional 220 VAC/12 VDC charger is also available upon request.
