General Description
MAN0996_Iss 1_02/16 Touchpoint Plus
Pt. No. 3011M5044_EN 17 User Guide
3.2.2 Weights
Note: Based on one input module, two mA output modules, two output relays, SMPS and backup battery for the basic unit
and expansion unit respectively.
TPPL Basic Unit TPPL Expansion Unit
System alone
8.5 Kg (18.7 lbs) 8 Kg (17.6 lbs)
System with packaging
9 Kg (20 lbs) 8.5 Kg (18.7 lbs)
Table 3. System Weights
3.2.3 Dimensions
External Dimension Millimetres Inches
Depth
156 6.2
Length
426 16.9
Width
300 11.8
Table 4. System Dimensions
3.2.4 Ambient Operating Temperature
–10 °C to +55 °C (14 °F to 131 °F)
3.2.5 Overall Ambient Operating Humidity
5 % to 95 %RH, non-condensing
3.2.6 Storage Conditions (Without batteries)
–25 °C to +60 °C (-13 °F to 140 °F), @ 5 % to 95 %RH, non-condensing
3.2.7 Storage Conditions (With batteries)
1 year: –20 °C to +25 °C (–4 °F to +077 °F)
3 months: –20 °C to +45 °C (–4 °F to +113 °F)
1 month: –20 °C to +60 °C (–4 °F to +140 °F)
3.2.8 IP Rating
The enclosures are sealed to IP65 when appropriate cable entry glands are used.
3.2.9 Construction
The system cabinets are constructed from PC ABS plastic with a secured quick release front access door panel.
The Controller door panel holds a touch sensitive colour LCD with a membrane cover over additional buttons, LEDs and
an audible warning horn.
Inside the Controller cabinet is a Switched-Mode Power Supply (SMPS) providing a nominal DC 24 V output, an optional
Lithium-ion backup battery, a Main Module, a mA/mV Input Module, two mA Output Modules, two Relay Modules,
protection fuses, and the control and user interface electronics.
The optional expansion unit holds the same modules and optional backup battery, but has no controller or user interface.
Both enclosures contain a common Earth (ground) rail that must be bonded to Protective Earth (Ground) through an
isolation switch that does not disconnect the Earth line.
