Honeywell Touchpoint Plus User Manual

Safety
MAN0996_Iss 1_02/16 Touchpoint Plus
Pt. No. 3011M5044_EN 8 User Guide
2.2 Location and Description of Warning Labels
2.2.1 Safety Warning Labels
In accordance with the requirements of European Standard EN 60825–1, appropriate warning labels are mounted in
specified locations on the equipment. This is to indicate conditions under which the user could be subjected to electrical
hazards.
Figure 1. Quick Start Guide Label
(Not to Scale)
Figure 2. Rating Label
(External – Not Shown Below)
Figure 3. Protective Earth (Ground) Point Figure 4. Equipment Earth (Ground) Point
This Protective Earth (Ground) location point label is
used inside the system and is not normally visible to
the operator.
This Equipment Earth (Ground) location point label is
used inside the system and is not normally visible to
the operator.
Figure 5. Internal Label Positions

Honeywell Touchpoint Plus Specifications

General

Brand	Honeywell
Model	Touchpoint Plus
Category	Controller
Language	English
