Honeywell Touchpoint Plus User Manual

Icon Glossary
MAN0996_Iss 1_02/16 Touchpoint Plus
Pt. No. 3011M5044_EN 59 User Guide
Chapter 12. Icon Glossary
#
Icon Description
#
Icon Description
1
Summary View Alarm
28
Trend Graph
2
Summary View Normal
29
Processing Ok
3
Summary View
30
Processing Failed
4
List View
31
Cancel
5
Tile View
32
Scroll Start
6
Output View
33
Scroll Stop
7
Information Menu
34
List Up
8
Event History Information
35
List Down
9
Event History Alarm
36
Move Up
10
Event History Fault
37
Move Down
11
Event History Inhibit
38
Move Left
12
Event History Warning
39
Move Right
13
No One Logged In
40
Maintenance Menu
14
Operator Logged In
41
System Setting Menu
15
Service Logged In
42
Configuration Menu
16
Administrator Logged In
43
Configuration
17
Menu Select
44
Calibration
18
Mains Power On
45
Inhibit
19
Mains Off, Batteries On
46
Channel Location
20
SD Card Good
47
Base Line Adjust
21
SD Card Not Good
48
Peak Reset
22
Alarm Filter
49
Trend
23
Fault Filter
50
Alarm Pop Up
24
Inhibit Filter
51
Error Pop Up
25
Warning Filter
52
Fault Pop Up
26
Filter Information
53
Inhibit Pop Up
27
Filter Refresh
54
Warning Pop Up

Honeywell Touchpoint Plus Specifications

General

Mounting	Panel
Communication	Ethernet
Communication Ports	1 x Ethernet, 2 x USB
Power Supply	24 VDC
Enclosure Rating	IP65 (front)
