Specifications
MAN0996_Iss 1_02/16 Touchpoint Plus
Pt. No. 3011M5044_EN 55 User Guide
Chapter 10. Technical Specifications
10.1 Environmental
Sealed enclosures are rated IP65 NEMA 4x, and can be installed indoors only in a Pollution Degree 2, 10 to 95 %RH Non-
Condensing environment that affords total protection from rain, snow and direct sunlight.
Operating Temperature
-10 °C to + 55 °C
Storage Temperature
-25 °C to + 60 °C
Operating Humidity (closed)
10 to 90 %RH (non-condensing)
10.2 User Interface and Main Module
LCD Touch Screen Type
7’ TFT Colour LCD with LED Backlight (resistive touch screen)
800 x 480 pixels (WVGA) Resolution
Active area 155.08 mm (H) x 86.92 mm (V)
Front Display
Green Power LED
Red Alarm LED
Yellow Fault/inhibit LED
Alarm Mute /Reset Push Button
Alarm Buzzer (Sound Level: 70 dB at 1 m)
Communication Outputs
1) 10/100 Mbps Ethernet Interface with standard RJ-45 connector
2) RS-485 Modbus connections supporting 115.2 kbps max.
Output Relays
Two configurable and one fixed System State Relays:
1.7 A @ 250 VAC, 1.7 A @ 30 VDC (non-inductive load)
Dedicated Audio and Visual alarm
Four outputs to external devices
Supply voltage Vs (18 32 VDC) 1.8* VDC (max), max 300 mA
per channel
*Voltage drop at ambient temperature
Remote Terminals Optional remote acknowledge, reset and inhibit
10.3 External Power Supplies
SMPS Power Supply
156 W
AC Input Voltage Range (~)
AC 110/220 V ±10 % of nominal (manual switching)
DC Input Voltage Range (
)
DC 1832 V SELV Supply
Input Frequency Range (~)
AC 5060 Hz ± 6 %
Output Voltage (
)
DC 24 V
Dimension
199 x 98 x 38mm (L x W x H)
