Installation Instruction VARIODYN
®
D1 System
FB 798663.GB0 / 05.19 51
6.4.1 Specification - UIM
Audio inputs
Nominal level : 0 dBu
Max. level : + 6 dBu
Frequency range : 20 Hz … 22 kHz
Signal-to-noise ratio : > 95 dB
Distortion factor at nominal level : < 0.05 %
Audio outputs
Nominal level : 0 dBu
Frequency range : 20 Hz … 22 kHz
Signal-to-noise ratio : > 85 dB
Distortion factor at nominal level : < 0.05 %
Output impedance : 200 Ω
XLR socket : Symmetrical, potential-free
CINCH socket : Asymmetrical, potential-free
XLR socket
Type : Symmetrical potential-free
Input impedance : 100 kΩ
CINCH socket
Type : Asymmetrical potential-free
Input impedance : 1 kΩ
Control contacts
Input contact
Max. input voltage : max. 24 V DC (over DAL-Bus)
Input voltage logical 0 : > 8.5 V DC @ 5,6 kΩ
Input voltage logical 1 : < 7.5 V DC @ 4,5kΩ
Input resistance :
10 k
Ω
Output contact
Max. external voltage
:
24 V DC
Load current per output : max. 50 mA
Short-circuit proof against + 24 V
:
1 secound
General specifications
Power consumption
:
< 150 mA @ 24 V DC
Ambient temperature :
-5 °C … +55 °C
Storage temperature :
-10 °C … +60 °C
Humidity
:
15 % … 90 % rel. hum. (non-condensing)
Housing : metal
Colour
:
grey, similar to RAL 7016
Weight net / gross : 3,6 kg
Dimensions of unit (W x H x D)
:
483 x 44 x 345 mm (1 HU)
Specification : EN 54-16
