CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
63-4528—04 118
09-23
Communication Decoding
Method
0: Definition (20XX)
1: Definition (60XX)
1
09-24 COM1 Protocol
0: RS485
1: BACnet
0
09-25 PLC Address
1~254
2
09-26 CANopen Slave Address
0: Disable
1~127
0
09-27 CANopen Speed
0: 1M
1: 500k
2: 250k
3: 125k
4: 100k
5: 50k
0
09-28 CANopen Frequency Gain 1.00 ~ 2.00 1.00
09-29 CANopen Warning Record
bit 0: CANopen Guarding Time out
bit 1: CANopen Heartbeat Time out
bit 2: CANopen SYNC Time out
bit 3: CANopen SDO Time out
bit 4: CANopen SDO buffer overflow
bit 5: Can Bus Off
bit 6: Error protocol of CANopen
0
09-30
CANopen Decoding
Standard
0: Communication definition of VFD CORE series
1: CANopen DS402 Standard
1
09-31
CANopen Communication
Status
0: Node Reset State
1: Com Reset State
2: Boot up State
3: Pre Operation State
4: Operation State
5: Stop State
0
09-32 CANopen Control Status
0: Not Ready For Use State
1: Inhibit Start State
2: Ready To Switch On State
3: Switched On State
4: Enable Operation State
7: Quick Stop Active State
13: Err Reaction Active State
14: Error State
0
09-33 Reset CAN Initial Idx
bit0: reset address 20XX to 0.
bit1: reset address 264X to 0
bit2: reset address 26AX to 0
bit3: reset address 60XX to 0
65535
09-34 CANopen Master function
0: Use 420XX
1: Use 60XX
0
09-35 CAN Master / Slave 0: Diable; 1:Enable Master 0
09-36 CANopen Master Address
1~127
100
09-37 BACnet Dnet MAC ID 0~127 10
09-38 BACnet Baud Rate 96~384 Kbps 384
09-39 BACnet Device ID L 0~65535 1
09-40 BACnet Device ID H 0~63 0
Table 10. Communication Parameters
Parameter Explanation Settings
Factory
Setting
