Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
119 63-4528—04
09-41 BACnet Polling Address 0~127 127
09-42 BACnet Password 0~65535 0
09-43
Identification of
Communication Card
0: No communication card
1: DeviceNet Slave
2: Profibus-DP Slave
3: CANopen Slave
4: Modbus-TCP Slave
5: EtherNet/IP Slave
6~8: Reserved
0
09-44
Firmware Version of
Communication Card
Read Only
##
09-45 Product Code
Read Only
##
09-46 Error Code
Read Only
##
09-47
Address of Communication
Card
DeviceNet: 0-63
Profibus-DP: 1-125
1
09-48 Communication Card Speed
Standard DeviceNet:
0: 100Kbps
1: 125Kbps
2: 250Kbps
3: 1Mbps
Non standard DeviceNet:
0: 10Kbps
1: 20Kbps
2: 50Kbps
3: 100Kbps
4: 125Kbps
5: 250Kbps
6: 500Kbps
7: 800Kbps
8: 1Mbps
2
09-49
Other settings of
communication card speed
0: Disable
In this mode, baud rate can only be 0,1,2,3 in standard
DeviceNet speed
1: Enable
In this mode, the baud rate of DeviceNet can be same as
CANopen (0-8)
0
09-50
IP Configuration of the
Communication Card
0: Static IP
1: Dynamic IP (DHCP)
0
09-51
IP Address 1 of the
Communication Card
0~255
0
09-52
IP Address 2 of the
Communication Card
0~255
0
09-53
IP Address 3 of the
Communication Card
0~255
0
09-54
IP Address 4 of the
Communication Card
0~255
0
09-55
Address Mask 1 of the
Communication Card
0~255
0
Table 10. Communication Parameters
Parameter Explanation Settings
Factory
Setting
