Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
63-4528—04 120
09-56
Address Mask 2 of the
Communication Card
0~255
0
09-57
Address Mask 3 of the
Communication Card
0~255
0
09-58
Address Mask 4 of the
Communication Card
0~255
0
09-59
Gateway Address 1 of the
Communication Card
0~255
0
09-60
Gateway Address 2 of the
Communication Card
0~255
0
09-61
Gateway Address 3 of the
Communication Card
0~255
0
09-62
Gateway Address 4 of the
Communication Card
0~255
0
09-63
Password for
Communication Card (Low
word)
0~99
0
09-64
Password for
Communication Card (High
word)
0~99
0
09-65 Reset Communication Card
0: No function
1: Reset to return to the factory setting
0
09-66
Additional Setting for
Communication Card
Bit 0: Enable IP Filter :
Bit 1: Enable internet parameters (1bit)
Once the setup of internet parameter is done, the Bit 1
will be enabled. But after the parmeters of the
communication card are updated, this Bit 1 will be
disabled.
Bit 2: Enable login password (1bit)
When login password is correctly entered, the Bit 2 will
be enabled. But after the parameters of the
communication card are updated, this Bit 2 will be
disabled.
0
09-67
Status of Communication
Card
Bit 0: Enable password.
When the communication card is locked by a password,
this Bit 0 will be enabled. When the password is clear,
this Bit 0 will be disabled.
0
Table 10. Communication Parameters
Parameter Explanation Settings
Factory
Setting
