CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
155 63-4528—04
• This parameter selects the functions for each multi-function terminal.
• The terminals of Pr.02-34~Pr.02-39 will only be displayed after using with optional card I/O Extension Card and Relay
Extension Card
22: Over-current stall prevention warning
23: Over-voltage stall prevention warning
24: Operation mode indication
25: Forward command
26: Reverse command
27: Output when current >= Pr.02-31 (>= 02-31)
28: Output when current ≤Pr.02-31 (≤ 02-31)
29: Output when frequency >= Pr.02-32 (>= 02-32)
30: Output when frequency ≤ Pr.02-32 (≤02-32)
31: Y-connection for the motor coil
32: D-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed include stop (actual output frequency)
35: Error output selection 1(Pr.06-22)
36: Error output selection 2(Pr.06-23)
37: Error output selection 3(Pr.06-24)
38: Error output selection 4(Pr.06-25)
40: Speed attained (including Stop)
44: Low current output
45: UVW Magnetic Contactor enabled
47: Brake output closed
50: Output for CANopen control
51: Output for RS485
52: Output for communication card
53: Fire mode indication
54: Bypass fire mode indication
55: Motor #1 Output
56: Motor #2 Output
57: Motor #3 Output
58: Motor#4 Output
59: Motor#5 Output
60: Motor #6 Output
61: Motor#7 Output
62: Motor#8 Output
