CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
185 63-4528—04
• This is the operating mode of a drive after Pr.06-26 is set to define PTC detection.
• It needs to set AVI1/ACI/AVI2 analog input function Pr.03-00~03-02 to 6 (P.T.C. thermistor input value).
• It is used to set the PTC level, and the corresponding value for 100% is max. analog input value.
• When malfunction occurs, use can check the frequency command. If it happens again, it will overwrite the previous record.
• When malfunction occurs, use can check the current frequency command. If it happens again, it will overwrite the previous
record.
• When malfunction occurs, user can check current output voltage. If it happens again, it will overwrite the previous record.
85~100: Reserved
101: CGdE CANopen software disconnect1
z
102: CHbE CANopen software disconnect2
z
103: CSYE CANopen synchronous error
z
104: CbFE CANopen hardware disconnect
z
105: CIdE CANopen index setting error
z
106: CAdE CANopen slave station number setting error
z
107: CFrE CANopen index setting exceed limit
z
a
06 - 26
PTC (Positive Temperature Coefficient) Detection Selection
Factory Setting: 0
Settings 0: Warn and keep operating
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
a
06 - 27 PTC Level
Factory Setting: 50.0
Settings 0.0~100.0%
a
06 - 28 Frequency Command for Malfunction
Factory Setting: Read Only
Settings 0.00~655.35Hz
06 - 29 Output Frequency at Malfunction
Factory Setting: Read Only
Settings 0.00~655.35Hz
06 - 30 Output Voltage at Malfunction
Factory Setting: Red Only
Settings 0.0~6553.5V
06 - 31 DC Voltage at Malfunction
Factory Setting: Read Only
Settings 0.0~6553.5V
