Honeywell VFD CORE

CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
195 63-4528—04
22 Motor 1 over load (EoL1) V Not detectable Not detectable
23 Motor 2 over load (EoL2) V Not detectable Not detectable
24 Over heat 3 (oH3) (PTC) V V (able to auto-reset) V
26 Over torque 1 (ot1) V Not detectable Not detectable
27 Over torque 2 (ot2) V Not detectable Not detectable
30 EEPROM write error (cF1) V Not detectable Not detectable
31 EEPROM read error (cF2) V V Not detectable
33 U phase current sensor detection error (cd1) V V Not detectable
34 V phase current sensor detection error (cd2) V V Not detectable
35 W phase current sensor detection error (cd3) V V Not detectable
36 Hardware Logic error 0 (Hd0) - cc V V Not detectable
37 Hardware Logic error 1 (Hd1) - oc V V Not detectable
38 Hardware Logic error 2 (Hd2) - ov V V Not detectable
39 Hardware Logic error 3 (Hd3) – occ V V Not detectable
40 Motor auto tuning error (AuE) V Not detectable Not detectable
41 ACI feedback loss (AFE) V Not detectable Not detectable
48 ACI Loss V Not detectable Not detectable
49 External fault (EF) V Not detectable Not detectable
50 Emergency stop (EF1) V Not detectable Not detectable
51 base block (bb) V Not detectable Not detectable
52 PcodE (Password) V Not detectable Not detectable
53 Software code lock (ccodE) V Not detectable Not detectable
54 Communication error 1 (cE1) V Not detectable Not detectable
55 Communication error 2 (cE2) V Not detectable Not detectable
56 Communication error 3 (cE3) V Not detectable Not detectable
57 Communication error 4 (cE4) V Not detectable Not detectable
58 cE10 (Communication Time Out) V Not detectable Not detectable
59 Communication time out (cP10) V Not detectable Not detectable
60 Braking Transistor Fault (bf) V Not detectable Not detectable
61 Y-Honeywell connected Error (ydc) V Not detectable Not detectable
62 Decel. Energy Backup Error (dEb) V Not detectable Not detectable
63 Over Slip Error (oSL) V Not detectable Not detectable
64 MC Fault over Frame E V Not detectable Not detectable
66 Unknown oc V(RS) V (able to auto-reset) V
67 Unknown ov V(RS) V (able to auto-reset) V
73 S1-Emergy STOP V V Not detectable
74 Fire Mode V V (keeps on operating) V (keeps on
operating)
79 A PHASE SHORT V V (able to auto-reset) V
80 B PHASE SHORT V V (able to auto-reset) V
81 C PHASE SHORT V V (able to auto-reset) V
Table 4. Error detection under Normal mode, Fire mode and Bypass function at Fire mode (V means detectable)
Code Error name Normal
mode
Fire Mode Enable bypass
function
