Honeywell VFD CORE

CHAPTER 7: OPTIONAL COMPONENTS
65 63-4528—04
Frame E
Fig. 6. Panel Cutout Diagram Frame E: Unit in in. (mm)
[4] M12*P1.75 OR
[4] Ø33/64 (Ø13)
21-1/4
(540)
13-3/16 (335)
15-1/8 (384)
7/16 (11)
37/64 (15)
M33385
