CHAPTER 10: DIGITAL KEYPAD
63-4528—04 92
Startup in Digital Keypad
1. The default Start-up page is Honeywell Logo, displayed for 3 seconds
2. Selection Screen. Choose how to interact with the VFD.
— Press F4: Initials the Startup Wizard
— Press Menu: Redirect to the main menu
— Press Esc: Redirect to the monitor screen
RIGHT and LEFT arrows to move the cursor with a numeric parameter, or to enter into and out of menus.
UP and DOWN arrows used to change numeric parameter values, or cycle through menu options.
Function Keys - will have different functions at different times as displayed on the screen. Used during
Wizard Mode.
Pressing the HAND key will take the VFD into Hand control, where the user can control the motor
Frequency and START and STOP.
Pressing this key will revert the VFD to remote/Automatic control from a remote speed and start
command source.
Table 2. Descriptions of LED Functions
LED Descriptions
Steady ON: operation indicator for the VFD, including DC brake, zero speed, standby, restart after fault
and speed search.
Blinking: VFD is decelerating to stop.
Steady OFF: VFD is not running.
Steady ON: VFD is stopped.
Blinking: VFD is in the standby status.
Steady OFF: VFD running.
Operation Direction LED (green: forward running, red: reverse running).
Blinking: drive is changing the operation direction.
HAND LED: HAND LED is on (HAND mode); HAND LED is off (AUTO mode).
AUTO LED: AUTO LED is on (AUTO mode); AUTO LED is off (HAND mode).
Table 1. Descriptions of Keypad Functions
