12
THE MS9540 VOYAGERCG SERIES
How to Use CodeGate and the Manual Activation Mode
CODEGATE MANUAL ACTIVATION MODE*
*
This feature is not a default setting.
Refer to the MetroSelect Configuration
Guide for instructions on enabling the
Manual Activation Mode.
Figure 11. Figure 12.
Three Modes of Operation
Auto Trigger, In-Stand
• Auto-triggers while in the stand
• Bar code is automatically decoded and transmitted
CodeGate, Out-of-Stand
• CodeGate activates when removed from the stand
• Bar code data is transmitted when the button is pressed
Manual Activation Mode*, Out-of-Stand
• Button activates laser
• Bar code data is scanned and transmitted while button is held down
