APPLICATIONS AND PROTOCOLS
The model number on each scanner includes the scanner number and factory
default communication protocol.
Scanner Version Identifier Communication Protocol(s)
MS9520
Or
MS9540
00 Laser Emulation and RS232 Transmit/Receive
11 RS485, RS232 - TXD, RXD, RTS, CTS
14 RS232 - TXD, RXD, RTS, CTS, DTR, DSR
38
Low Speed USB,
Serial Emulation or Keyboard Emulation
40 Full Speed Integrated USB
41 RS232/Light Pen Emulation
47
Keyboard Wedge, Stand-Alone Keyboard and
TTL RS232 Transmit/Receive
The MS9520/9540 Keyboard Wedge Series (-47) is designed for keyboard
emulation only. Many RS232 configurable functions available in other Honeywell
scanners are also available as keyboard wedge functions.
The following are the most important selectable options specific to keyboard
wedge:
Keyboard Type
• **AT (includes IBM
®
• IBM PS2 (includes models 30, 70, 8556)
PS2 models 50, 55, 60, 80)
Keyboard Country Type
•
**USA
•
Italian
•
Swiss
•
Belgian
•
Japanese
•
Swedish/Finnish
•
French
•
Russian Cyrillic
•
Turkish
•
German
•
Slovenian
•
United Kingdom
•
Hungarian
•
Spanish
** Default setting. Refer to the MetroSelect
®
Configuration Guide
(
PN 00-02407) or MetroSet2’s help files for information on how to change the
default settings.
