SCANNER AND CABLE TERMINATIONS
Scanner Pinout Connections
MS95x0-00 Laser Emulation
Pin Function
1
Ground
2 RS232 Transmit Output
3 RS232 Receive Input
4
Flip Sense/Start of Scan Output
5
Proximity Detect/Trigger Emulation Output
6 Scan/Laser Enable Input
7 Reserved
8
Data Out
9
+5VDC
10 Shield Ground
MS95x0-14 RS232
MS95x0-40 Full Speed USB &
MS95x0-38 Low Speed USB
Pin Function Pin Function
1 Ground 1 Ground
2 RS232 Transmit Output 2 RS232 Transmit Output
3
RS232 Receive Input
3
RS232 Receive Input
4
RTS Output
4
RTS Output
5 CTS Input 5 CTS Input
6 DTR Input 6 D+
7
Reserved
7
PC +5V/V_USB
8
DSR Out
8
D-
9 +5VDC 9 N/C
10 Shield Ground 10 Drain Wire
