INSTALLATION MANUAL 29
COMBISLIM II
• The wiring diagram is located under the top panel
• The terminal/contactor for the electrical connection is located behind the back
plate. You have to remove the back plate, and then insert the main power cable
through the strain relief at the bottom of the oven.
Observe the color coding of the wires. Wrong connection may cause
electric shock. Yellow/green = earth connection, blue = neutral
To ensure that the oven can be disconnected during installation and
repair, an approved plug outlet or safety cut-out must be located
close to the oven. The safety cut-out must be able to automatically
cut o all poles with a total distance of break of at least 3 mm. Each
of the two units in a stacked arrangement (CombiPlus) must have its
own plug outlet or safety cut-out.
Improper electrical installation will invalidate your warranty.
During installation, always follow the installation instructions and the information provided
on the rating plate and ensure that the installation complies with local rules and regulations.
We recommend that you use a HPFI protection relay (type B) RCD/RCCB 30 mA because
an uneven current may be supplied from the frequency inverter in the oven.
