HP Compaq nc6000 - Notebook PC User Manual

5–8 Maintenance and Service Guide
Removal and Replacement Procedures
6. Remove the hard drive by following these steps:
a. Turn the notebook upside down, with the rear panel
facing you.
b. Remove the T8M2.5×5.0 screw 1 that secures the hard
drive door to the notebook.
c. Remove the PM3.0×4.0 hard drive security screw 2 that
secures the hard drive to the notebook.
Removing the Hard Drive Screws
Spare Part Number Information
Hard drives (include hard drive frame and connector)
80-GB (5400-rpm)
60-GB (7200-rpm)
60-GB (5400-rpm)
40-GB (5400-rpm)
30-GB (4200-rpm)
344407-001
365438-001
344406-001
344405-001
344404-001

HP Compaq nc6000 - Notebook PC Specifications

General

Processor	Intel Pentium M
Chipset	Intel 855PM
Storage	30 GB to 60 GB HDD
Hard Drive Interface	ATA-100
Battery	6-cell Lithium-Ion
Operating System	Windows XP Professional
RAM	256 MB, upgradable to 2 GB
Graphics	ATI Mobility Radeon 9600
Display	14.1-inch
Display Resolution	1024 x 768 or 1400 x 1050
Optical Drive	DVD-ROM, CD-RW/DVD Combo, or DVD±RW
Networking	10/100/1000 Ethernet
Ports	2 x USB 2.0, VGA, parallel, serial, headphone, microphone
