Removal and Replacement Procedures
Maintenance and Service Guide 5–7
5. Remove the battery bezel by sliding it down and off of the
battery pack.
✎
The battery bezel is included in the Miscellaneous Plastics Kit,
spare part number 344411-001.
Removing the Battery Bezel
Reverse the above procedure to install the battery pack and
battery bezel.
