HP 1650B

OPATtern
OPATtern
command/query
The OPATtern command allows you to construct a pattern recognizer
term for the 0 Marker which is then used with the OSEarch criteria when
moving the marker on patterns. Since this command deals with only one
label at a time, a complete specification could require several invocations.
When the value of a pattern is expressed in binary, it represents the bit
values for the label inside the pattern reco p term. In whatever base
is used, the value must be between 0 and 2 - 1, since a label may not have
more than 32 bits. Because the c labelqattem > parameter may contain
don’t cares, it is handled as a string of characters rather than a number.
The OPATtern query returns the pattern specification for a given label
name.
Command Syntax:
:MACHine{ 1 I2):SLISt:OPATtern <label-name >, -z labelgattern >
where:
e label-name > :: = string of up to 6 alphanumeric characters
c label-pattern > ::= “{#B{Oll IX}. . . 1
%Q{O111213)41516)7JX)... I
%H(Ol1~2/3~4~5~6)7~8~9~A)BICJDIEIFIX). . . 1
{Oil ~2~3~4~5~6~7~8~9). }”
Examples: OUTPUT XXX;“:MACHINEl:SLIST:OPATTERN ‘DATA’,‘255’ *
OUTPUT XXX;“:MACHINEl:SLIST:OPATTERN ‘ABC’,‘#BXXXXllDl’ -
HP 1650B/HP 16518
Programming Reference
SLIST Subsystem
13-11
