Front bezel
1. Prepare the computer for disassembly (Preparation for disassembly on page 16).
2. Remove the access panel (Access panel on page 18).
3. Remove the optical drive (Optical drive on page 22).
4. Pull the four tabs upward (1), and then rotate the bezel o the computer (2).
IMPORTANT: A cable connects the power button in the bezel to the system board.
To install the front bezel, reverse the removal procedure.
26 Chapter 4 Removal and replacement procedures
