Processor
For a list of available processors, see Computer major components on page 4.
1. Prepare the computer for disassembly (Preparation for disassembly on page 16).
2. Remove the access panel (Access panel on page 18).
3. Remove the fan duct (Fan duct on page 32).
4. Remove the fan sink (Fan sink on page 33).
5. Pull the locking arm away from the processor (1), and the rotate the arm to its full open position (2).
6. Raise and rotate the microprocessor retainer to its fully open position (3).
7. Carefully lift the processor from the socket (4).
IMPORTANT: Do not handle the pins in the processor socket. These pins are fragile, and handling them
could cause irreparable damage. If pins are damaged, you might have to replace the system board.
To install a processor, reverse the removal procedure.
NOTE: After installing a new processor onto the system board, always update the system ROM to ensure
that the latest version of the BIOS is being used on the computer. The latest system BIOS can be found on the
Web at: http://www8.hp.com/us/en/support-drivers.html.
34 Chapter 4 Removal and replacement procedures
