HP 3100 Series User Manual

183
Step Command Remarks
3. Configure the
advertisable TLVs.
lldp tlv-enable
{
basic-tlv
{
all
|
port-description
|
system-capability
|
system-description
|
system-name
} |
dot1-tlv
{
all
|
port-vlan-id
|
protocol-vlan-id
[ vlan-id ] |
vlan-name
[ vlan-id ] } |
dot3-tlv
{
all
|
link-aggregation
|
mac-physic
|
max-frame-size
|
power
} |
med-tlv
{
all
|
capability
|
inventory
|
location-id
{
civic-address
device-type country-code
{ ca-type ca-value }&<1–10> |
elin-address
tel-number } |
network-policy
|
power-over-ethernet
} }
Optional.
By default, all types of
LLDP TLVs except
location identification TLVs
are advertisable on a
Layer 2 Ethernet port.
Configuring the management address and its encoding
format
LLDP encodes management addresses in numeric or string format in management address TLVs.
By default, management addresses are encoded in numeric format. If a neighbor encoded its
management address in string format, configure the encoding format of the management address as
string on the connecting port. This guarantees normal communication with the neighbor.
To configure a management address to be advertised and its encoding format on a port or group of
ports:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Enter Ethernet interface
view or port group view.
• Enter Layer 2 Ethernet
interface view:
interface interface-type
interface-number
• Enter port group view:
port-group manual
port-group-name
N/A
3. Allow LLDP to advertise
the management
address in LLDP
frames and configure
the advertised
management address.
lldp management-address-tlv
[ ip-address ]
Optional.
By default, the management address
is sent through LLDP frames.
For a Layer 2 Ethernet port, the
management address is the primary
IP address of the lowest-ID VLAN
carried on the port. If none of the
carried VLANs is assigned an IP
address, no management address will
be advertised.
4. Configure the encoding
format of the
management address
as string.
lldp
management-address-format
string
Optional.
By default, the management address
is encapsulated in the numeric format.
Setting other LLDP parameters
The Time to Live TLV carried in an LLDPDU determines how long the device information carried in
the LLDPDU can be saved on a recipient device.
