• Discovering the IP phones connected to Ethernet 1/0/1 and Ethernet 1/0/2.

• Obtaining their LLDP device information.

[SwitchA] display lldp neighbor-information

CDP neighbor-information of port 1[Ethernet1/0/1]:

CDP neighbor index : 1

Chassis ID : SEP00141CBCDBFE

Port ID : Port 1

Software version : P0030301MFG2

Platform : Cisco IP Phone 7960

Duplex : Full

CDP neighbor-information of port 2[Ethernet1/0/2]:

CDP neighbor index : 2

Chassis ID : SEP00141CBCDBFF

Port ID : Port 1

Software version : P0030301MFG2

Platform : Cisco IP Phone 7960

Duplex : Full
