113
MAC Addr From Port Port Index
Gigabitethernet1/0/1 is link-up
MAC address authentication is enabled
Authenticate success: 1, failed: 0
Max number of on-line users is 2048
Current online user number is 1
MAC Addr Authenticate state Auth Index
00e0-fc12-3456 MAC_AUTHENTICATOR_SUCCESS 29
# After the user passes authentication, use the display connection command to display the online user
information.
<Device> display connection
Slot: 1
Index=29 ,Username=00-e0-fc-12-34-56@aabbcc.net
IP=N/A
IPv6=N/A
MAC=00e0-fc12-3456
Total 1 connection(s) matched on slot 1.
Total 1 connection(s) matched.
RADIUS-based MAC authentication configuration example
Network requirements
As shown in Figure 34, a host connects to port GigabitEthernet 1/0/1 on the access device. The device
uses RADIUS servers for authentication, authorization, and accounting.
Perform MAC authentication on port GigabitEthernet 1/0/1 to control Internet access. Make sure that:
• The device detects whether a user has gone offline every 180 seconds. If a user fails authentication,
the device does not authenticate the user within 180 seconds.
• All MAC authentication users belong to ISP domain 2000 and share the user account aaa with
password 123456.
Figure 34 Network diagram
Configuration procedure
1. Make sure the RADIUS server and the access device can reach each other.
2. Create a shared account for MAC authentication users on the RADIUS server, and set the
username aaa and password 123456 for the account.
3. Configure the device:
IP network
GE1/0/1
DeviceHost
RADIUS servers
Auth:10.1.1.1
Acct:10.1.1.2
