48
4. Configure a WFQ queue.
qos wfq queue-id group { 1 |
2 } { byte-count | weight }
schedule-value
Select weight or byte-count according
to the WFQ type (byte-count or
packet-based) you have enabled.
By default, all queues are in WFQ group
1 and have a weight of 1.
5. (Optional.) Configure the
minimum guaranteed
bandwidth for a WFQ
queue.
qos bandwidth queue queue-id
min bandwidth-value
The default setting is 64 kbps for each
queue.
Configuration example
Network requirements
Configure byte-count WFQ queuing on interface Ten-GigabitEthernet 1/0/1.
Assign queues 1, 3, 4, 5, and 6 to WFQ group 1, with their weights being 2, 5, 10, 10, and 10,
respectively, and assign queues 0, 2, and 7 to WFQ group 2, with their weights being 1, 2, and 4,
respectively.
Configure the minimum guaranteed bandwidth as 100 Mbps for each queue.
Configuration procedure
# Enter system view.
<Sysname> system-view
# Configure byte-count WFQ queuing on interface Ten-GigabitEthernet 1/0/1.
[Sysname] interface ten-gigabitethernet 1/0/1
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq byte-count
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 1 group 1 byte-count 2
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 3 group 1 byte-count 5
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 4 group 1 byte-count 10
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 5 group 1 byte-count 10
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 6 group 1 byte-count 10
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 0 group 2 byte-count 1
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 2 group 2 byte-count 2
[Sysname-Ten-GigabitEthernet1/0/1] qos wfq 7 group 2 byte-count 4
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 0 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 1 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 2 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 3 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 4 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 5 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 6 min 100000
[Sysname-Ten-GigabitEthernet1/0/1] qos bandwidth queue 7 min 100000
Configuring SP+WRR queuing
Configuration procedure
