c. Repeat the previous two steps to add other devices.

Figure 8 Adding a CPE

After the CPE is added successfully, a success message is displayed, as shown in Figure 9.

Figure 9 CPE added successfully

5. Configure the system settings of the ACS, as shown in Figure 10.
