Power Keys
@OWER/SWEEP]
Pressing the (POWER/SWEEP] key displays the power sweep value and allows
it to be changed.
This function controls the change in RF power as the instrument sweeps,
with units of dB/Sweep. If this key is pressed when power sweep mode is off,
or when another parameter is displayed in the MARKER/SWEEP/STATUS
area, then power sweep becomes the active parameter, and the PWR SWP
annunciator is turned on. Pressing the key again turns power sweep mode
off, and turns the PWR SWP annunciator off.
A positive or negative value may be entered. The power must remain within
the ALC leveling range, and may not cross an attenuator boundary.
The value of power at the start of the sweep will be displayed in the POWER
area, and will be automatically varied if necessary to keep the power
within the ALC leveling range. The display format is
F’wt-
C;I.~.IIX~=
XX.
ME:.
Resolution is 0.1
dB.
Associated SCPI Commands
POWer:MODE
SWEep
Turns power sweep mode on.
POWer:MODE
FIXed
Turns power sweep mode
OK
POWer:STARt Qmn>[DBM1
Sets the start of the power sweep
to the desired value.
POWer:SPAN
<num>[DBM]
Sets the power span to the desired
value.
Associated 8350 Commands
PSI
<num>[suffixl
Turns power sweep on.
PSO
Turns power sweep
ofi:
13-5
