HP A5800 Series

77
A5800-48G (1 slot)/A5800-48G TAA (1 slot)
panel views
Figure 71 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet
port
(2) 10/100/1000Base-T Ethernet port LED
(3) Seven-segment LED
(4) Port mode LED
(5) SFP+ port LED
(6) Logo plate (A console port and a USB port are
under this logo plate)
(7) System status LED (SYS)
(8) RPS status LED (RPS)
(9) Interface card status LED (SLOT1)
(10) SFP+ port
(11) Port LED mode switching button
To use the console port and USB port, open the logo plate.
Figure 72 Open the logo plate
