Power Supply
Operating Voltage Range (STD PS)
Operating Voltage Range (EPA 87/89/85% @ 20/50/100% load PS)
Rated Voltage Range (STD PS)
Rated Voltage Range (EPA 87/89/85% @ 20/50/100% load PS)
Rated Line Frequency
115V
90-264 VAC
90-264 VAC
100-240 VAC
100-240 VAC
50-60 Hz
230V
90-264 VAC
90-264 VAC
100-240 VAC
100-240 VAC
50-60 Hz
Power Output 320W 320W
Rated Input Current (maximum)
1
STD PS
EPA 87/89/85% @ 20/50/100% load PS
5.5A @ 115 VAC
5.5A @ 115 VAC
2.75A @ 230 VAC
2.75A @ 230 VAC
1
This system utilizes an active power factor corrected power supply. This allows the system to pass the CE mark requirements
for use in the countries of the European Union. The active power factor corrected power supply also has the added benefit of
not requiring an input voltage range select switch.
Table F-1 Specifications (continued)
238 Appendix F Specifications
