Access Panel
1. Prepare the computer for disassembly (Preparation for Disassembly on page 76).
CAUTION: Before removing the computer access panel, ensure that the computer is turned off
and that the power cord is disconnected from the electrical outlet.
2. Loosen the two captive thumbscrews (1) that secure the access panel to the computer chassis.
3. Use the handle located between the thumbscrews to lift the access panel off the unit (2).
NOTE: You may want to lay the computer on its side to install internal parts. Be sure the side
with the access panel is facing up.
Figure 8-2 Removing the Computer Access Panel
To install the access panel, reverse the removal procedure.
Access Panel 77
