4. Open both latches of the memory module socket (1), and insert the memory module into the socket
(2).
NOTE: A memory module can be installed in only one way. Match the notch on the module with
the tab on the memory socket.
A DIMM must occupy the black DIMM1 socket.
For maximum performance, populate the sockets so that the memory capacity is spread as equally
as possible between Channel A and Channel B.
5. Push the module down into the socket, ensuring that the module is fully inserted and properly
seated. Make sure the latches are in the closed position (3).
6. Repeat steps 4 and 5 to install any additional modules.
7. Replace the access panel.
8. If the computer was on a stand, replace the stand.
9. Reconnect the power cord and turn on the computer.
10. Lock any security devices that were disengaged when the access panel was removed.
The computer should automatically recognize the additional memory the next time you turn on the
computer.
Installing Additional Memory 119

Table of Contents

Other manuals for HP Compaq dc7800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq dc7800 and is the answer not in the manual?

HP Compaq dc7800 Specifications

General IconGeneral
Tcase73.3 °C
Bus typeFSB
SteppingM0
Processor cache2 MB
Processor cores2
Processor modelE4600
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo E4000 Series
Processor socketLGA 775 (Socket T)
Processor codenameConroe
Processing Die size111 mm²
Processor frequency2.4 GHz
Processor cache typeL2
Processor lithography65 nm
Processor manufacturerIntel
Processor front side bus800 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)65 W
CPU multiplier (bus/core ratio)12
Number of Processing Die Transistors167 M
Internal memory1 GB
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)2 x 0.5 GB
HDD speed7200 RPM
HDD interfaceSATA
Optical drive typeDVD Super Multi
Total storage capacity160 GB
Audio input1
LightScribeYes
Networking featuresIntel 82566DM Gigabit Network Connection
Graphics card RAMDAC400 MHz
Storage drive controllerSATA 3, 0 Gb/s NCQ SMART VI
Discrete graphics card modelIntel® GMA 3100
Maximum graphics card memory0.256 GB
Operating system installedWindows Vista Business
USB 2.0 ports quantity8
Chassis typeMini Tower
Country of originChina
Cable lock slot typeKensington
Operating altitude0 - 3048 m
Non-operating altitude0 - 9144 m
Storage temperature (T-T)-30 - 60 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Power supply365 W
Product typePC
Processor codeSLA94
Processor ARK ID32242
Processor package size37.5 x 37.5 mm
Weight and Dimensions IconWeight and Dimensions
Depth452 mm
Width177 mm
Height447 mm
Weight11800 g
