Page #35 background imageLoading...
Page #35 background image
3. For Windows Vista, click Install Altiris DAgent.
For Windows XP, click Install Altiris AClient.
4. Follow the onscreen instructions to set up and configure the Altiris client.
The Altiris Deployment Solution Agent is a key infrastructure component for enabling the HP Client
Foundation Suite and the Client Premium Suite. To learn about the other infrastructure components
necessary for implementing the HP Client Foundation Suite and Client Premium Suite, please visit
http://www.hp.com/go/easydeploy.
Verdiem Surveyor Client Side Installation
1. If the software is pre-installed, select the icon on the Start menu.
-or-
Download and run a softpaq that contains the software.
2. From the Welcome screen, click Next.
3. Click Change to select where you want to install the client and client data, and then click Next.
4. Type in the server name, port, an a preferred group (optional), and then click Next.
NOTE: This is the only location you can enter server information. The only way to change this
information after installation is to uninstall/reinstall or change a registry key.
NOTE: The make the Next button active, click out of the Surveyor Server Name field.
5. Click Install to install the software.
6. Click Finish after the installation is complete.
Remote System Installation
Remote System Installation allows you to start and set up the system using the software and
configuration information located on a network server by initiating the Preboot Execution Environment
(PXE). The Remote System Installation feature is usually used as a system setup and configuration
tool, and can be used for the following tasks:
Formatting a hard drive
Deploying a software image on one or more new PCs
Remotely updating the system BIOS in flash ROM (
Remote ROM Flash on page 32)
Configuring the system BIOS settings
To initiate Remote System Installation, press F12 when the F12 = Network Service Boot message
appears in the lower-right corner of the HP logo screen when the computer is booting up. Follow the
instructions on the screen to continue the process. The default boot order is a BIOS configuration setting
that can be changed to always attempt to PXE boot.
Remote System Installation 23

Table of Contents

Other manuals for HP Compaq dc7800

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq dc7800 and is the answer not in the manual?

HP Compaq dc7800 Specifications

General IconGeneral
Tcase73.3 °C
Bus typeFSB
SteppingM0
Processor cache2 MB
Processor cores2
Processor modelE4600
System bus rate- GT/s
Processor familyIntel® Core™2 Duo
Processor seriesIntel Core 2 Duo E4000 Series
Processor socketLGA 775 (Socket T)
Processor codenameConroe
Processing Die size111 mm²
Processor frequency2.4 GHz
Processor cache typeL2
Processor lithography65 nm
Processor manufacturerIntel
Processor front side bus800 MHz
Processor operating modes64-bit
ECC supported by processorNo
Thermal Design Power (TDP)65 W
CPU multiplier (bus/core ratio)12
Number of Processing Die Transistors167 M
Internal memory1 GB
Internal memory typeDDR2-SDRAM
Maximum internal memory8 GB
Memory layout (slots x size)2 x 0.5 GB
HDD speed7200 RPM
HDD interfaceSATA
Optical drive typeDVD Super Multi
Total storage capacity160 GB
Audio input1
LightScribeYes
Networking featuresIntel 82566DM Gigabit Network Connection
Graphics card RAMDAC400 MHz
Storage drive controllerSATA 3, 0 Gb/s NCQ SMART VI
Discrete graphics card modelIntel® GMA 3100
Maximum graphics card memory0.256 GB
Operating system installedWindows Vista Business
USB 2.0 ports quantity8
Chassis typeMini Tower
Country of originChina
Cable lock slot typeKensington
Operating altitude0 - 3048 m
Non-operating altitude0 - 9144 m
Storage temperature (T-T)-30 - 60 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Power supply365 W
Product typePC
Processor codeSLA94
Processor ARK ID32242
Processor package size37.5 x 37.5 mm
Weight and Dimensions IconWeight and Dimensions
Depth452 mm
Width177 mm
Height447 mm
Weight11800 g
