HP Compaq dc7800 - System Board Drive Connections

System Board Drive Connections
Refer to the following illustration and table to identify the system board drive connectors.
No. System Board Connector System Board Label Color
1 Media Card Reader MEDIA black
2 Diskette Drive FLOPPY black
3 SATA0 SATA0 dark blue
4 SATA1 SATA1 white
5 SATA4 SATA4 light blue
Drives 129
