HP Compaq Elite 8300 Touch All-in-One Business User Manual

Antenna
The antenna route from the WLAN card to the top of the computer.
To remove the antenna:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 40).
2. Remove the access panel (see
Access panel on page 45).
3. Remove the optical drive (see
Replacing the optical disc drive on page 57).
4. Remove the stand (see
Stand on page 48).
5. Remove the lower panel (see
Lower panel on page 50).
6. Remove the metal plate (see
Metal plate on page 51).
7. Remove the power supply (see
Power supply on page 90).
8. Remove the side panels (see
Side panels on page 88).
9. Remove the speakers (see
Speakers on page 86).
10. Remove the system board (see
System board on page 93).
11. Remove the front bezel (see
Front bezel on page 105).
Antenna
109
