HP Compaq Elite 8300 Touch All-in-One Business User Manual

Solving Power Problems
Common causes and solutions for power problems are listed in the following table.
Table 8-2 Solving Power Problems
Power supply shuts down intermittently.
Cause Solution
If equipped with a voltage selector, voltage selector switch on
rear of computer chassis (some models) not switched to
correct line voltage (115V or 230V).
Select the proper AC voltage using the selector switch.
Power supply will not turn on because of internal power
supply fault.
Replace the power supply.
Computer powered off automatically and the Power LED flashes Red two times, once every second,
followed by a two second pause, and the computer beeps two times. (Beeps stop after fifth iteration but
LEDs continue flashing.)
Cause Solution
Processor thermal protection activated:
A fan may be blocked or not turning.
OR
The heat sink is not properly attached to the processor.
1. Ensure that the computer air vents are not blocked and
the processor cooling fan is running.
2. Open the access panel, press the power button, and see
if the processor fan (or other system fan) spins. If the fan
does not spin, make sure the fan cable is plugged onto
the system board header.
3. If fan a plugged in and not spinning, replace it.
Solving Power Problems
129

HP Compaq Elite 8300 Touch All-in-One Business Specifications

General

Touchscreen	Yes
Brightness	250 cd/m²
Response Time	5 ms
Aspect Ratio	16:9
Display Size	23 inches
Resolution	1920 x 1080
Contrast Ratio	1000:1
Video Input	VGA, DisplayPort
Connectivity	USB 2.0, USB 3.0
