HP Compaq Elite 8300 Touch All-in-One Business User Manual

Stand
The stand is secured with two captive Torx screws. You must remove a plastic cover to gain access to
the screws. You must remove the access panel to remove the stand.
To remove the stand:
1. Prepare the computer for disassembly (see
Preparing to disassemble the computer on page 40).
2. Remove the access panel (see
Access panel on page 45).
3. Push the release button (1) on the bottom of the stand and pull the back of the stand off (2).
Figure 7-9 Removing the back of the stand
4. Push the base of the stand down (1), and loosen the two captive Torx screws securing the stand to
the chassis (2).
Figure 7-10 Releasing the stand
48 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis

HP Compaq Elite 8300 Touch All-in-One Business Specifications

General

Brand	HP
Model	Compaq Elite 8300 Touch All-in-One Business
Category	Monitor
Language	English
