6. Remove the metal plate (see Metal plate on page 51).
7. Remove the power supply (see
Power supply on page 90).
8. Remove the speakers (see
Speakers on page 86).
9. Remove the side panels (see
Side panels on page 88).
10. Remove the front bezel (see
Front bezel on page 105).
11. Disconnect the backlight cable from the display panel.
NOTE: Replace the backlight cable with the new backlight cable that comes with the new
display panel kit.
Remove the backlight cable from the defective panel before sending the panel back to the
supplier.
Figure 7-79 Disconnecting the backlight cable from the display panel
112 Chapter 7 Removal and Replacement Procedures All-in One (AIO) Chassis
