HP Compaq Pro 6300 Series Small Form Factor User Manual

Processor
Description Spare part number
Intel Core i7 processor
3770, 3.4 GHz (turbo up to 3.9 GHz), 8-MB L3 cache, 77W 688164-001
2600, 3.4 GHz (turbo up to 3.8 GHz), 8-MB L3 cache, 95W 638632-001
Intel Core i5 processors
3570, 3.4 GHz, 6-MB L3 cache, 95W 688162-001
3470, 3.2 GHz, 6-MB L3 cache, 95W 687943-001
2400, 3.1 GHz, 6-MB L3 cache 638630-001
Intel Core i3 processors
3240, 3.4 GHz, 3-MB L3 cache 688951-001
3225, 3.3 GHz, 3-MB L3 cache, 55W 689578-001
3220, 3.3 GHz, 3-MB L3 cache, 65W 688950-001
2130, 3.4 GHz, 3-MB L3 cache 665120-001
2120, 3.3 GHz, 3-MB L3 cache 638629-001
Intel Pentium processors
G2120, 3.1 GHz, 3-MB L3 cache 703282-001
G870, 3.1 GHz, 3-MB L3 cache 691936-001
G860, 3.0 GHz, 3-MB L3 cache 665123-001
G850, 2.9 GHz, 3-MB L3 cache 655973-001
G645, 2.9 GHz, 3-MB L3 cache 704228-001
G640, 2.8 GHz, 3-MB L3 cache 691935-001
G630, 2.7 GHz, 3-MB L3 cache 665122-001
Intel Celeron processors
G555, 2.7 GHz, 2-MB L3 cache 704227-001
G550, 2.6 GHz, 2-MB L3 cache 691934-001
G540, 2.5 GHz, 2-MB L3 cache 665119-001
G530T, 2.0 GHz, 2-MB L3 cache 665118-001
G465, 1.9 GHz, 1.5-MB L3 cache 706883-001
G460, 1.8 GHz, 1-MB L3 cache 682410-001
1. Prepare the computer for disassembly (Preparation for Disassembly on page 94).
2. Remove the access panel (
Access Panel on page 95).
3. Remove the fan duct (
Fan duct on page 119).
128 Chapter 7 Removal and Replacement Procedures Small Form Factor (SFF) Chassis

HP Compaq Pro 6300 Series Small Form Factor Specifications

General

Form Factor	Small Form Factor
Expansion Slots	1 PCIe x16, 1 PCIe x1, 1 PCI
Processor	Intel Core i3/i5/i7
Chipset	Intel Q75 Express
Memory	Up to 32 GB DDR3-1600 SDRAM
Storage	128 GB Solid State Drive
Graphics	Integrated Intel HD Graphics
Optical Drive	DVD-ROM
Operating System	Windows 7, Windows 8, FreeDOS
USB Ports	6 USB 2.0
Ports	VGA, DisplayPort, RJ-45, Serial, PS/2, Audio in/out
Network	Integrated Intel 82579LM Gigabit Ethernet
Power Supply	240W
Dimensions	338 x 379 x 100 mm (13.3 x 14.9 x 3.9 in)
Weight	7.6 kg (16.7 lbs)
Audio	Integrated HD audio
