Misc parts
Item Description Spare part number
(1) Chassis fan 645327-001
(2) Fan duct (not illustrated) 636921-001
(3) Heat sink (includes replacement thermal material) 645326-001
(4) Speaker 636925-001
(5) Solenoid lock 641471-001
(6) Printer port, PCI card 638817-001
(7) Hood sensor 638816-001
Rubber feet 583654-001
Chassis stand 587451-001
38 Chapter 4 Illustrated parts catalog

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq Pro 6300 Series Small Form Factor and is the answer not in the manual?

HP Compaq Pro 6300 Series Small Form Factor Specifications

General IconGeneral
Form FactorSmall Form Factor
Expansion Slots1 PCIe x16, 1 PCIe x1, 1 PCI
ProcessorIntel Core i3/i5/i7
ChipsetIntel Q75 Express
MemoryUp to 32 GB DDR3-1600 SDRAM
Storage128 GB Solid State Drive
GraphicsIntegrated Intel HD Graphics
Optical DriveDVD-ROM
Operating SystemWindows 7, Windows 8, FreeDOS
USB Ports6 USB 2.0
PortsVGA, DisplayPort, RJ-45, Serial, PS/2, Audio in/out
NetworkIntegrated Intel 82579LM Gigabit Ethernet
Power Supply240W
Dimensions338 x 379 x 100 mm (13.3 x 14.9 x 3.9 in)
Weight7.6 kg (16.7 lbs)
AudioIntegrated HD audio
