Small Form Factor (SFF) chassis spare parts
Computer major components
Item Description Spare part number
(1) Front bezel 687950-001
Bezel blank (optical drive; not illustrated) 570838-001
Bezel blank (diskette drive; not illustrated) 583653-001
(2) Access panel 646815-001
(3) Power supply
240W, 90% efficient 613762-001
240W, standard 613763-001
(4) System board (includes replacement thermal material)
For use in models without Windows 8 657239-001
For use in models with Windows 8 Standard 657239-501
For use in models with Windows 8 Professional 657239-601
For use in models with NetClone (available only in China) 710095-001
Small Form Factor (SFF) chassis spare parts 35

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Compaq Pro 6300 Series Small Form Factor and is the answer not in the manual?

HP Compaq Pro 6300 Series Small Form Factor Specifications

General IconGeneral
Form FactorSmall Form Factor
Expansion Slots1 PCIe x16, 1 PCIe x1, 1 PCI
ProcessorIntel Core i3/i5/i7
ChipsetIntel Q75 Express
MemoryUp to 32 GB DDR3-1600 SDRAM
Storage128 GB Solid State Drive
GraphicsIntegrated Intel HD Graphics
Optical DriveDVD-ROM
Operating SystemWindows 7, Windows 8, FreeDOS
USB Ports6 USB 2.0
PortsVGA, DisplayPort, RJ-45, Serial, PS/2, Audio in/out
NetworkIntegrated Intel 82579LM Gigabit Ethernet
Power Supply240W
Dimensions338 x 379 x 100 mm (13.3 x 14.9 x 3.9 in)
Weight7.6 kg (16.7 lbs)
AudioIntegrated HD audio
