Hardware options installation 43
12.
Remove the protective cover from the heatsink.
CAUTION: To prevent thermal instability and damage to the server, do not separate the
processor from the heatsink after assembling.
13. Install the heatsink, and then close the heatsink retaining latches.
14. Install the air baffle.
15. Install the access panel.
16. Do one of the following:
o Close or install the tower bezel, as needed.
o Slide the server back into the rack.
17. Power up the server (on page 22).
Memory options
