Table 3-2 Display component descriptions and part numbers (continued)
Item Component Spare part number
Models with an antiglare display N22923-001
Models with a BrightView display N22924-001
(7) Metal back cover for hinge arm N22925-001
(8) Hinge arm cover N22926-001
(9) Hinge arm support bracket (available in the Bracket Kit) N22931-001
(10) Hinge Kit
FHD displays N22935-001
OLED displays N26147-001
* Display back cover (metal, includes leather cover) N22920-001
* Display Misc Parts Kit (includes hinge Mylar, display insulator, display TOF rubber, bezel tape, panel
tape, panel absorber, touch control board adhesive, and display gaskets)
N22934-001
* LCD Adhesives Kit N31257-001
*not illustrated
Miscellaneous parts
To identify the miscellaneous parts, use this table.
Table 3-3
Miscellaneous part descriptions and part numbers
Component Spare part number
AC adapter
280 W, PFC, slim, 7.4 mm M52952-001
120 W, PFC, 7.4 mm L89695-001
120 W, PFC, 4.5 mm M95377-001
65 W, nPFC, USB-C®, 1.8 m [6.0 ft], slim L04650-850
65 W, nPFC, travel adapter L21487-001
65 W, nPFC, USB Type-C adapter, 1.8 m (6 ft) L67440-001
Screw Kit N22945-001
Cable Kit (includes pen charging cable, touchpad cable, SIM cable, audio cable, and transfer board cable) N22929-001
Display Cable Kit (includes FHD panel cable, OLED panel cable, privacy panel cable, EDP cable, camera
+ sensor cable, ALD cable, left IR camera cable, right RGB camera cable, TOF + microphone cable, CLS +
microphone cable, touch control board cable, and eCompass board cable)
N22930-001
Bracket Kit (includes left and right hinge arm brackets, solid-state drive bracket, display bracket, PBC
bracket, USB bracket, and WWAN 4G module bracket)
N22931-001
Rubber Kit (includes top bumper, WWAN module rubber, and middle and back trunk cover bumpers) N22933-001
20 Chapter 3Illustrated parts catalog
