HP Dragonfly Folio User Manual

5. Use a tool to release the board from the computer (5). The board is secured with adhesive.
To install the transfer board, reverse this procedure.
Touchpad
To remove the touchpad, use this procedure and illustration.
Table 5-10
Touchpad description and part number
Description Spare part number
Touchpad N22947-001
Touchpad cable (included in Cable Kit) N22929-001
Before removing the touchpad, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 33).
2. Remove the bottom cover (see Bottom cover on page 33).
3. Remove the battery (see Battery on page 42).
4. Remove the bottom speakers (see Bottom speakers on page 44).
Remove the touchpad:
1. Disconnect the touchpad cable from the touchpad ZIF connector (1).
2. Gently pull up to release the keyboard cable from the long strip of adhesive that secures it to the top of
the touchpad (2).
46
Chapter 5Removal and replacement procedures for authorized service provider parts

HP Dragonfly Folio Specifications

General

Graphics	Intel Iris Xe Graphics
Processor	12th Gen Intel Core i5 or i7
RAM	16 GB or 32 GB LPDDR5
Storage	512 GB, 1 TB, or 2 TB PCIe NVMe SSD
Operating System	Windows 11 Pro
Wireless	Intel Wi-Fi 6E AX211 (2x2) and Bluetooth 5.2
Ports	1 x Headphone/microphone combo
Audio	quad speakers
Security	Fingerprint reader, TPM 2.0
Weight	Starting at 2.99 lb (1.35 kg)
