8. Push the optical drive from behind, and then remove it from the front of the computer.
Figure 8-18 Removing the optical drive
Removing the Hard Drive
NOTE: Before you remove the old hard drive, be sure to back up the data from the old hard drive so
that you can transfer the data to the new hard drive.
The preinstalled 3.5-inch hard drive is located under the power supply. To remove and replace the
hard drive:
1. Prepare the computer for disassembly (
Preparation for Disassembly on page 101).
2. Remove the access panel (
Access Panel on page 102).
3. Remove the front bezel (
Front Bezel on page 104).
4. Rotate the drive cage to its upright position.
120 Chapter 8 Removal and Replacement Procedures Small Form Factor (SFF) Chassis
