5. Disconnect the cable from the red/brown system board connector labeled SYS_FAN1 (1), pull
the fan into the chassis until it clears the chassis lip, and then lift it out of the chassis (2).
Figure 7-42 Removing the fan
To install the fan, reverse the removal procedures.
System Fan 87
