Table 5-1 Bottom cover descriptions and part numbers
Description Spare part number
Bottom cover for use with computer models equipped with a 28 W processor N48858-001
Bottom cover for use with computer models equipped with an 18 W processor N09262-001
Before removing the bottom cover, prepare the computer for disassembly (see Preparation for
disassembly on page 38).
Remove the bottom cover:
1. Loosen the five Phillips captive screws that secure the bottom cover to the computer.
2. Use a nonmarking, nonconductive tool (1) to separate the rear edge of the bottom cover (2) from the
computer.
Bottom cover
39
