7. Remove the bezel from the display assembly (4).
NOTE: In these steps, the display assembly will not be connected to the computer as shown in the
illustration.
8. If you need to remove the raw display panel, remove the four Phillips PM2.0×3.0 screws (1) that secure
the display panel to the display enclosure.
9. Lift and rotate the panel onto the computer (2).
NOTE: In these steps, the display assembly will not be connected to the computer as shown in the
illustration.
94 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts ENWW
