10. Lift the tape that secures the display cable to the display panel (1), and the disconnect the display cable
from the panel (2).
11. Lift the display panel from the display enclosure.
12. If you need to replace the webcam/microphone module:
a. Release the tape that secures the webcam cable to the module (1).
b. Disconnect the cable (2) from the module.
CAUTION: Handle the module with caution. The module has a thin profile and is susceptible to
damage when not handled carefully.
ENWW Component replacement procedures 95
